Product Features:
Adjustable temperature control
Low voltage protection
Low resistance protection
High input voltage warning
Output short circuit protection
Reverse battery protection
Overheating prevention
Product Specifications:
Accommodates 2 18650 sized batteries
Variable wattage range: 5.0 - 200 watts
Output voltage range: 0.5 - 7.0 volts
Atomizer resistance range: 0.05 - 2.5 ohm
Battery voltage range: 6.2 - 8.4 volts
Temperature control range: 100 - 350°C / 212 - 662°F
Supports both Kanthal and nickel wires
INSTALLING THE BATTERIES:
Please install batteries before use. To ensure correct installation, follow these instructions: Open the battery panel; insert batteries into battery slots with the positive and negative poles aligned as illustrated; ensure ribbon is wrapped around batteries to remove the batteries easily. To remove the batteries, pull on the loose end of the ribbon to lift batteries out of their slot.
TURNING THE DEVICE ON:
Once batteries are installed, the device enters “turn-on mode” with the logo displayed, and will then enter into “lock mode” shortly after. Press the fire button 5 times consecutively within 3 seconds to unlock the device. After unlocking the device, atomizer resistance, output wattage, output voltage, battery level, and current regulated temperature will be displayed. Without an atomizer installed, the output voltage will read 0.00V and resistance will read 0.00Ω. If you attempt to fire without an atomizer installed, “CHECK ATOMIZER” will be displayed.
LOCKING THE DEVICE:
The device can be locked by pressing the "+" and fire buttons simultaneously. The screen will display "System Locked" and no buttons will work on the device. Pressing the "+" and fire buttons again will unlock the device.
SETTING YOUR RESISTANCE:
Every time you put an atomizer on the device, you will need to set its resistance. To set a resistance, press the "-" and fire buttons simultaneously. You will see "Cold Coil? Yes + \ No -" displayed on the screen. The coil must be cold to get an accurate read. If your coil is cold, press the "+" button and the resistance will set.
ADJUSTING THE WATTAGE:
If you would like to adjust the wattage, press both the “+” and “-” buttons simultaneously until the “W” in front of the wattage value is flashing. Now by pressing the “+” or “-” buttons you can increase or decrease the wattage respectively. The output wattage range is 5.0 to 200.0W. By pressing “+” below 50W, watts increase by 0.1 increment; above 50W, watts increase by 0.5 increments; above 100W, watts increase by 1 increment. By pressing “-”, below 50W, watts decrease by 0.1 increment; above 50W, watts decrease by 0.5 increments; above 100W, watts decrease by 1 increment. When wattage is higher than 150W, the system is pulse output and the upper right corner of the screen will display a "P" symbol.
ADJUSTING THE TEMPERATURE:
NOTE: Only when using pure nickel wires in your atomizer build will the temperature control function work. Ordinary wires can only make use of the watt adjustment function.
If you would like to adjust the temperature, press both the “+” and “-” buttons simultaneously until the “°C” or “°F” in front of the temperature value is flashing. Now by pressing the “+” or “-” buttons you can increase or decrease the temperature respectively. The temperature range is 100-350°C / 212-662°F. By pressing the “+” or “-”, temperature will increase or decrease by 1°C / 1°F. The system can switch between °C and °F by scrolling pass the minimum or maximum temperatures. (i.e. when you click “+” upwards to 662°F and continue to hold the button, it will automatically switch to 350°C; when you click “-“ downwards to 212°F and continue to hold the button, it will automatically switch to 100°C, and vice versa.)
TURNING THE DEVICE OFF:
Press the fire button 5 times in 3 seconds consecutively anytime during standby mode to turn off the device. “ASMODUS” will then read on the display. Pressing the button 5 times again will turn the device back on.
BATTERY INFORMATION:
When battery voltage is lower than 6.2V, device will display “LOW BATTERY”. When battery power is low and does not match the current wattage or temperature setting, device will display ”CHECK BATTERY” and stop firing. When battery voltage is less than 5.4V, device will not power on; when this display appears, change batteries before use.
RESISTANCE RANGE:
This device supports only a resistance range from 0.05Ω - 2.5Ω, otherwise the device will not fire. When the resistance is lower than 0.05Ω, “LOW ATOMIZER” will be displayed and will not fire; when the resistance is higher than 2.5Ω, “HIGH ATOMIZER” will be displayed; when there is no atomizer, “CHECK ATOMIZER” will be displayed; when the atomizer shorts, “ATOMIZER SHORT” will be displayed.
